Cryptotian Consumer Electronics

Dropshipping AK7 Mini pc Win10 pro In-tel J3455 4GB 64GB dual WIFI 4K HD

Dropshipping AK7 Mini pc Win10 pro In-tel J3455 4GB 64GB dual WIFI 4K HD

$526.62 USD
$526.62 USD $526.62 USD
Sale Sold out
Shipping calculated at checkout.
Memory Capacity
Color
Hard Drive Capacity

Dropshipping AK7 Mini pc  Win10 pro In-tel J3455 4GB 64GB dual WIFI  4K HD  mini computer for business



Product Description




AK7 mini pc.jpgdaul HD MINI PC.jpgwindows 10 pro mini pc.jpgintel J3455 mini pc.jpgsupport dual screen display mini copmuter.jpg4K HD mini computer.jpg



  Specifications:




Product Appearance
Type Spec. Standard Configuration Optional
Product Product Type MINI PC, Ad Terminal Box
Dimension 123mm*123mm*22.8mm
Case Material The upper shell is plastic, the middle shell and the bottom shell are metal
Weight Net Weight 277g,Gross Weight 515g
System Hardware Configuration
Type Spec. Description Optional
CPU Model In-tel  J3455
Speed 1.5GHz  ( J3455)   1.1GHz(N3350)
Max. Turbo Speed 2.3GHz  ( J3455)  2.4GHz(N3350)
Power Consumption   10W/6W
Memory Model LPDDR3
Capacity LPDDR4     Max 12GB on Board
Storage EMMC eMMC Max 128GB
SSD Optional,mSATA SSD,Max 512GB
2.5" SSD No Supporting
TF Card TF Card Max 128GB
RTC BIOS Real-time Clock, Time Boot
Auto Power On BIOS Support auto power on after electrified
Diskless Network BIOS Support uefi/Legacy Diskless Switch On
TPM CPU integratesTPM Support TPM 2.0
Dual Display Video Output Support HD1+HD2 dual display
LED State Green light- Swith on
Red light- Switch off
Internet Connection
Type Spec. Description Optional
WIFI Model In-tel 7265/ 3165/ RTL8821CE on board
Protocol IEEE 802.11 a, b/g, n, ac
BT Model In-tel 7265/ 3165/ RTL8821CE  on board
Protocol Support BT 4.2
3G Built-in No
4G Built-in No
Ethernet LAN1 10M/100M/1000M Self-adaption
I/O
Type Spec. Description Optional
USB USB2.0 USB2.0 Type-A*2
USB USB3.0 USB3.0 Type-A*2
TF Expansion Memory TF*1
HD AV Output HD 1.4b Type A  x2
VGA Gigabyte Ethernet No
RJ45 Data Transmission RJ45 x1
Uart Power Button No
POWER  Power Button x1
DC IN Power Supply Input 5.5/2.1mm DC Jack x1
Audio-in/out Audio-in/out 3.5mm Phone Jack x1 (Two-in-one interface)
Antenna1 FPC Antenna WiFi 2.4+BT x1
Antenna2 FPC Antenna WIFI 5.0
SIM Micro SIM No
Software Configuration
Type Spec. Description Optional
OS Version Win10 Home/Win10 pro/Win10 IOT/ U-buntu
Environment
Type Spec. Description Optional
Environment Working Temperature 0~40℃
Memory Temperature -20~60℃
Humidity 90% @ 40 °C (No Condensation)
Accessory
Type Spec. Description Optional
Power Supply Vesa Input 100~240V 50/60Hz
Output 12V/2.5A  DC 5.5/2.1mm
IR Remote Control No Supporting
VESA Mount No Supporting

Pl
Application


OEM&ODM

How to select expected items in the various & complex market?

How to Select = High Quality + Strict Quality Control + Aging Time + Prompt Shipping Time + Professional & Quick Reply + Risk Free

Miraco= Assured Quality + 5 Steps Strict QC + 48 Hours Aging Time + Ship in 24 Hours + Superior 99.8% Customer Satisfaction + 2 year Warranty + Easy Return Policy



OEM:

1.Logo printing on housing

2.Customize package

3.Software Customization: Booting image,UI,APP,Function and so on.

ODM:

1.PCBA design

2.Housing design

3.Software Customization: Booting image,UI,APP,Function and so on.
